Specification
Features
- + Easy to operate
- + Internal sliding sash
- + Good U-value
- + Narrow profiles that provide better light entry
- + Can be supplied with solid colored profiles
- + Maintenance-friendly
- + Long service life
- + Recyclable - profiles consisting of 36% is recycled PVC
Fiberglass threshold
Low door threshold with a height of 48mm + 5 mm sliding rail. Threshold can be installed lower during construction.
Profile
The Trend profiles are made of extruded, through-dyed, impact-resistant and climate-resistant PVC profiles with very good insulating properties, which give a good U-value. Steel reinforcements are added to the profiles for extra strength and stability. Frame depth 197 mm.
Hardware
Segenia HST
Handle
Standard with external handle, internal handle in aluminum without locking cylinder. Can also be supplied with other solutions.
Dimensions
The doors are produced to order and according to your measurements and wishes. The lift-and-slide door is supplied in the following sizes:
| Sliding door | Min | Max |
|---|---|---|
| Width | 1988 | 3988 |
| Height | 1988 | 2588 |
Certain other sizes/solutions can be delivered on request. Please contact us.
Color
Standard white (RAL 9016). A selection of other colors is available on request. See our website for more information and available colors: See Colors
Can be supplied with solid-colored profiles.
Glass
Supplied with 3-layer glass. Safety glass on both sides is standard. We can supply various types of functional glasses. Functional glasses are supplied such as sun dampening, self-cleaning, anti-fog, noise-absorbing glass. Choose the right glass based on your needs and get the desired effect.
Internal groove
Supplied as standard without groove. It can be delivered at an additional cost with click-on profile for 10x10mm internal groove (utforingsnot)
Tests
Driving rain density according to EN 12208: 9A U-value: Good U-values. Determined, among other things, by the glass insulating ability and will depend on size.
Maintenance
The PVC profiles do not require maintenance, just cleaning with normal water soapy water. The locking system and fittings require ordinary cleaning and lubrication.
